[Lithium Battery Cabinet]
Material |
| 2.0T Steel Fire-resistant power coating
|
Size |
| [LBC-H1800] W1200 x D600 x H1800mm (2-door type) [LBC-H1200]
W1200 x D600 x H1200mm (2-door type)
|
Structure |
| 40mm double layer storage cabinet, piano hinges, double-layer fire door, 3 internal black shelves, three 10-port aluminum multi-taps, heavy duty casters
|
Agent Capacity |
| 4kg of dedicated lithium battery extinguishing agent (penetrating agent, smothering, cooling)
|
Weight |
| Varies by option(Base weight: 220kg)
|
Display/ ControlPanel |
| Thermometer, warning light/buzzer, on/off, emergency stop button, reset button
|
Electrical Specification |
| 220V single-phase, 30A circuit breaker
|
Features |
| ① 40mm gap double-layer structure(ensures safety during explosions) ② Temperature alarm settings customizable to on-site conditions ③ Activation of warning light and buzzers, along with overcharging cutoff, when the set temperature is reached ④ Active fire suppression through the discharge of dedicated lithium battery ⑤ Capable of charging up to 30 batteries simultaneously ⑥ Fire door structure that automatically closes in the event of a fire |
